Wattson Audio’s Madison Power S

The Wattson Audio Madison Power S is a compact, purpose-built power supply designed to elevate the performance of Wattson Madison Streamers. Developed around the same power-supply philosophy shared by Wattson Audio and CH Precision, Madison Power S delivers ultra-clean, tightly regulated power to help preserve timing, spatial detail, dynamic contrast, and low-level musical information.

Key Features

• Purpose-built power supply for Wattson Madison Streamers
• Compatible with all Madison Streamers, past and present
• Hybrid power design combining switching regulation with linear control
• Precision power line filter to reduce unwanted noise and high-frequency interference
• Passive and active filtering for refined DC power delivery
• Substantial energy storage for voltage stability under dynamic load conditions
• Discrete bipolar transistor regulator for ultra-low-noise output
• Intelligent monitoring and electronic protection systems
• Automatically reduces power draw below 0.5W in standby
• Milled aluminum chassis for mechanical stability and electromagnetic isolation
• Designed to visually and physically complement the Madison Streamer
• Available in Light Gray or Dark Gray

Why We Love It

The Madison Power S is a logical upgrade for Madison Streamer owners who want to get the most from their digital source. By lowering the noise floor and supplying cleaner, more stable current, it allows the streamer to present music with greater dimensionality, sharper dynamic contrasts, and a more stable soundstage. It is also designed as a true visual companion to the Madison Streamer, giving the system a clean, unified look while improving the foundation of digital playback.

Technical Specifications

General

• Type: Power supply
• Color Options: Light Gray or Dark Gray
• Dimensions: 175 x 155 x 87 mm
• Weight: 2.3 kg
• Power Supply: Universal AC input, 100–240V AC, 50/60Hz
• Power Consumption: <0.5W with no load or Madison Streamer in standby
• Primary Fuse: 5mm x 20mm, slow blow, T500mA 250VAC
• Monitoring and Electronic Protection: Over-voltage, over-current, short-circuit, and high-temperature protection

Output

• Output Voltage: 30V DC
• Maximum Output Current: 3.0A
